JST 1.0mm Pitch SHD 20 30 Pin Connector Wire Harness, SHDR-30V-S-B

Part Number:
SHDR-20V-S-B, SHDR-30V-S-B, SHDR-40V-S-B

Keywords:
1.0mm Pitch 30 Pin Wire Harness, 30 Pin Connector Wire Harness, JST SHD Connector Wiring Harness

Description:
FLECONN can custom JST 1.0mm Pitch SHD 20 30 Pin Connector Cable Wire Harness with housing SHDR-20V-S-B, SHDR-30V-S-B, SHDR-40V-S-B.

General Description:
Pitch: 1.0mm, Current rating: 0.5-1A, Voltage rating, 50V, Applicable Wire: Conductor size /AWG #32 to #28AWG, Insulation O.D. 0.4 to 0.8mm, Wire Stype: UL1571, UL1061

Product Description

1.0mm Pitch JST SH Connector Wire Harness, 2 3 4 5 6 7 8 9 10 Pin

Product Description:

FLECONN can custom jst SHD series dual row connector cable wire harness for manufacturers in the fields of Consumer Electronics Devices, Automotive, LED Light, Equipment and Machinery, Industry Automation System, Household Appliances, Medical Devices etc.

I. JST Housing Series

Circuits	Housing
20	SHDR-20V-S-B
30	SHDR-30V-S-B
40	SHDR-40V-S-B
50	SHDR-50V-S-B

II. Crimp Terminal

Crimp Terminal: SSH-003GA-P0.2

Applicable conductor size: 0.032-0.08mm2, 32AWG - 28AWG

Insulation OD: 0.4mm - 0.8mm

III. Product Specifications

1. Electrical Performance:
Rating voltage: 50V AC DC
Rating Current: 0.5 - 1.0A
Applicable Wire: UL1571, UL1061 AWG #32 to #28AWG

2. Temperature
operating temperature, fixed installation: -25 to 80c deg.
Service: Wiring Harness OEM
Certificate: CE, RoHS

IV. Product Pictures

JST 1.0mm Pitch SHDR-30V-S-B 30 Pin Connector Wire Harness

JST 1.0mm Pitch SHDR-30V-S-B 30 Pin Connector Wire Harness.jpg

JST 1.0mm Pitch Double Row 30 Pin Connector Wire Harness

JST 1.0mm Pitch Double Row 30 Pin Connector Wire Harness.jpg

JST 1.0mm Pitch SHD Connector Wire Harness, 20 30 40 50 Pin

JST 1.0mm Pitch SHD Connector Wire Harness.jpg
