1.5mm Pitch JST ZE ZER Connector Wire Harness, 2 3 4 5 6 8 10 Pin
  • 1.5mm Pitch JST ZE ZER Connector Wire Harness, 2 3 4 5 6 8 10 Pin
1.5mm Pitch JST ZE ZER Connector Wire Harness, 2 3 4 5 6 8 10 Pin

1.5mm Pitch JST ZE ZER Connector Wire Harness, 2 3 4 5 6 8 10 Pin

Part Number:
ZER-02V-S, ZER-03V-S, ZER-04V-S, ZER-06V-S
Keywords:
JST ZE Connector Wire Harness, 1.5 mm Pitch JST ZER Wire Harness
Description:
FLECONN can custom 1.5mm Pitch JST ZE ZER Connector Wire Harness with the housing of ZER-02V-S ZER-03V-S ZER-04V-S ZER-05V-S ZER-06V-S ZER-08V-S ZER-09V-S ZER-10V-S.
General Description:
Pitch: 1.5mm, Current rating: 2A, Voltage rating, 100V, Applicable Wire: Conductor size /AWG #30 to #24AWG, Insulation O.D. 0.76 to 1.2mm, Wire Stype: UL1571, UL1061

Product Description

1.5mm Pitch JST ZE ZER Connector Wire Harness, 2 3 4 5 6 8 10 Pin

Product Description:

FLECONN can custom 2 pin - 16pin 1.5mm pitch JST ZE series connector wire harness for the manufacturers in the fields of Consumer Electronics Devices, Automotive, LED Light, Equipment and Machinery, Industry Automation System, Household Appliances, Medical Devices etc.


I. JSTHousing Series

1.5mm Pitch JST ZE series wire to board connector housing

Circuits

Housing

2ZER-2
3ZER-3
4ZER-4
5ZER-5
6ZER-6
7ZER-7
8ZER-8
9ZER-9
10ZER-10
11ZER-11
12ZER-12
13ZER-13
14ZER-14
15ZER-15
16ZER-16

II. Crimp Terminal

   Crimp Terminal: SZE-002T-P0.3 / SZE-003T-P0.3
   Applicable conductor size: 28AWG - 24AWG / 30AWG - 26AWG
   Insulation OD: 0.76mm - 1.2mm / 0.76mm - 1.0mm


III. Product Specifications

   1. Electrical Performance:
   Rating voltage: 100V AC DC
   Rating Current: 2.0A (24AWG)
   Applicable Wire: UL1571, UL1061 AWG #30 to #24AWG

   2. Temperature
   operating temperature, fixed installation: -25 to 80c deg.
   Service: Wiring Harness OEM
   Certificate: CE, RoHS

IV. Product Pictures

JST 1.5mm Pitch ZE Connector Wire Harness

JST 1.5mm Pitch ZE Connector Wire Harness.jpg

JST 1.5mm Pitch ZE ZER Series Wire Harness

JST 1.5mm Pitch ZE ZER Series Wire Harness.jpg
