Custom JST 1.0mm Pitch SHLD 20 30 40 Pin Connector Wire Harness

Product Description:

FLECONN can custom jst SHLD series dual row connector wire harness for manufacturers in the fields of Consumer Electronics Devices, Automotive, LED Light, Equipment and Machinery, Industry Automation System, Household Appliances, Medical Devices etc.


I. JST Housing Series

CircuitsHousingHousing (with Secure Lock)
20SHLDP-20V-S(B)SHLDP-20V-S-1(B)
30SHLDP-30V-S(B)SHLDP-30V-S-1(B)
40SHLDP-40V-S(B)SHLDP-40V-S-1(B)
50SHLDP-50V-S(B)SHLDP-50V-S-1(B)


II. Crimp Terminal

Crimp Terminal: SSHL-003GA1-P0.2

Applicable conductor size: 32AWG - 28AWG

Insulation OD: 0.4mm - 0.8mm


III. Product Specifications

   1. Electrical Performance:
   Rating voltage: 50V AC DC
   Rating Current: 0.5 - 1.0A
   Applicable Wire: UL1571, UL1061 AWG #32 to #28AWG

   2. Temperature
   operating temperature, fixed installation: -25 to 80c deg.
   Service: Wiring Harness OEM
   Certificate: CE, RoHS
